Introducing the Zoom AMS-24 Audio Interface

The Zoom AMS-24 Audio Interface is expertly crafted for musicians looking to record tracks effortlessly with their DAW or stream live seamlessly on platforms such as YouTube and Twitch. Its innovative switch allows for a smooth transition between music production and live streaming, enhancing your creative experience.

When in Music mode, users can take advantage of advanced routing options tailored for individual input and output channels. Conversely, the Streaming mode merges all inputs into a single signal, facilitating direct streaming without the need for additional software.

This audio interface serves as an ideal solution not only for solo artists but also for collaborative sessions featuring multiple instruments. Key features include:

• Two XLR/TRS combo inputs equipped with low-noise Zoom preamps.
• Two headphone outputs and dual TRS outputs for connecting external monitors.
• A loopback switch that allows integration of input signals with playback audio from your computer, perfect for layering background music or combining live vocals with pre-recorded tracks.
• A Direct Monitor button that sends the input signal straight to your headphones while simultaneously routing it to your DAW or streaming program.
• The Music/Streaming switch enables quick toggling between recording and live broadcasting, allowing for independent control over multiple inputs and output mixes.

Key Specifications of the Zoom AMS-24 Audio Interface:

• For: Music recording and streaming
• Input Channels: 2
• Input Type: 2x XLR/TRS combo (Input 1: Hi-Z)
• Preamps: 2
• Phantom Power: 2
• Output Channels: 4
• Output Type: 2x TRS / 2 x Stereo 3.5mm
• Maximum Sample Rate: 96 kHz
• Interface: USB-C
• Maximum Bit Resolution: 24 bit

Included in the Package:

• 1x Zoom AMS-24 Audio Interface
